Infineon recommends a thermal pad on the bottom of the package, connected to a large copper area on the PCB to dissipate heat efficiently. A minimum of 2oz copper thickness is recommended, and the thermal pad should be connected to a ground plane to reduce thermal resistance.
To ensure reliable operation in high-temperature environments, it's essential to follow the recommended operating conditions, including junction temperature (Tj) and ambient temperature (Ta). Additionally, consider using thermal interface materials, such as thermal grease or thermal tape, to improve heat transfer between the device and the heat sink.
The ILD2111XUMA2 has built-in ESD protection, but it's still essential to follow proper ESD handling procedures during assembly and testing. Infineon recommends using an ESD wrist strap or mat, and ensuring that the device is handled in a static-safe environment.
The ILD2111XUMA2 is not hermetically sealed, so it's not recommended for use in high-humidity environments. However, if it's necessary to operate in a humid environment, consider using conformal coating or potting to protect the device from moisture.
Infineon recommends storing the ILD2111XUMA2 in a dry, cool place, away from direct sunlight and moisture. The storage temperature should be between -40°C and 125°C, and the relative humidity should be below 60%.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
ILD2111XUMA2 Overview
Use the download button to access the ILD2111XUMA2 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like ILD21,
or try a keyword search, such as Display Drivers
