IO6LC - ProTek Devices

IO6LC Details

• Manufacturer Part Number:

  IO6LC

• Part Life Cycle Code:

  Active

• Part Package Code:

  SOD

• Package Description:

  PLASTIC, SOP-8

• Pin Count:

  8

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  ProTek Devices

• YTEOL:

  5

• Additional Feature:

  LOW CAPACITANCE

• Configuration:

  COMPLEX

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• Forward Voltage-Max (VF):

  0.95 V

• JESD-30 Code:

  R-PDSO-G8

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  1

• Number of Elements:

  12

• Number of Terminals:

  8

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  245

• Polarity:

  UNIDIRECTIONAL

• Power Dissipation-Max:

  0.35 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  30 V

• Reverse Current-Max:

  0.1 µA

• Reverse Test Voltage:

  5.5 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
