IPL60R199CP - Infineon

IPL60R199CP Details

• Manufacturer Part Number:

  IPL60R199CP

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Not Recommended

• Package Description:

  VSON-4

• Pin Count:

  4

• Country Of Origin:

  Germany, Malaysia

• ECCN Code:

  EAR99

• Factory Lead Time:

  15 Weeks

• Manufacturer:

  Infineon Technologies AG

• YTEOL:

  3

• Avalanche Energy Rating (Eas):

  436 mJ

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  600 V

• Drain Current-Max (ID):

  16.4 A

• Drain-source On Resistance-Max:

  0.199 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JESD-30 Code:

  S-PSSO-N4

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  2A

• Number of Elements:

  1

• Number of Terminals:

  4

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Power Dissipation-Max (Abs):

  139 W

• Pulsed Drain Current-Max (IDM):

  51 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Position:

  SINGLE

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
