IPT60R050G7XTMA1 footprint, schematic symbol and 3D model by Infineon

Symbol

click to zoom

PCB Footprints

IPT60R050G7XTMA1 - Infineon PCB footprint - Other - Other - PG-HSOF-8-2

click to zoom

Datasheet Download Datasheet
Stock & Prices Price & Stock for IPT60R050G7XTMA1
Part Number IPT60R050G7XTMA1
Manufacturer Infineon
Pin Count 12
Part Category MOSFET (N-Channel)
Package Category Other
Footprint Name Other - PG-HSOF-8-2
Released Date Sep 14, 2020
Last Modified Date Mar 7, 2023 4:10 PM UTC
Pinout / Pin List Click Here (Member Only)

IPT60R050G7XTMA1 Details

Manufacturer Part Number:
IPT60R050G7XTMA1
Pbfree Code:
Yes
Rohs Code:
Yes
Part Life Cycle Code:
Active
Country Of Origin:
Austria, Germany, Malaysia
ECCN Code:
EAR99
Factory Lead Time:
17 Weeks
Manufacturer:
Infineon Technologies AG
YTEOL:
7
Avalanche Energy Rating (Eas):
159 mJ
Case Connection:
DRAIN
Configuration:
SINGLE WITH BUILT-IN DIODE
DS Breakdown Voltage-Min:
600 V
Drain Current-Max (ID):
44 A
Drain-source On Resistance-Max:
0.05 Ω
FET Technology:
METAL-OXIDE SEMICONDUCTOR
JESD-30 Code:
R-PSSO-F3
JESD-609 Code:
e3
Moisture Sensitivity Level:
1
Number of Elements:
1
Number of Terminals:
3
Operating Mode:
ENHANCEMENT MODE
Operating Temperature-Min:
-55 °C
Package Body Material:
PLASTIC/EPOXY
Package Shape:
RECTANGULAR
Package Style:
SMALL OUTLINE
Polarity/Channel Type:
N-CHANNEL
Pulsed Drain Current-Max (IDM):
135 A
Surface Mount:
YES
Terminal Finish:
Tin (Sn)
Terminal Form:
FLAT
Terminal Position:
SINGLE
Transistor Application:
SWITCHING
Transistor Element Material:
SILICON

IPT60R050G7XTMA1 Frequently Asked Questions (FAQs)

The maximum operating temperature range for the IPT60R050G7XTMA1 is -40°C to 150°C.
To ensure reliability, it's essential to follow the recommended thermal management guidelines, such as using a heat sink, and ensuring good airflow around the device.
The maximum current rating for the IPT60R050G7XTMA1 is 60A. However, it's essential to consider the device's thermal limitations and ensure that the current rating is within the safe operating area (SOA).
To protect the IPT60R050G7XTMA1 from overvoltage and overcurrent conditions, it's recommended to use a suitable voltage regulator and overcurrent protection circuitry, such as a fuse or a current limiter.
The recommended gate drive voltage for the IPT60R050G7XTMA1 is between 10V and 15V, with a maximum gate-source voltage of ±20V.
