IQ1B480HPD5CNRS-G - Synqor

IQ1B480HPD5CNRS-G Details

• Manufacturer Part Number:

  IQ1B480HPD5CNRS-G

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• YTEOL:

  8

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, EN, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  90%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  66 V

• Input Voltage-Nom:

  110 V

• JESD-30 Code:

  R-XDFM-P8

• JESD-609 Code:

  e3

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Output Current-Max:

  5.2 A

• Output Voltage-Max:

  52.8 V

• Output Voltage-Min:

  38.4 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DFM

• Package Shape:

  RECTANGULAR

• Package Style:

  MODULE

• Protections:

  OUTPUT OVER CURRENT; OUTPUT OVER VOLTAGE; THERMAL

• Surface Mount:

  NO

• Switching Frequency-Max:

  295 kHz

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  249.6 W

• Trim/Adjustable Output:

  YES
