IQ4H150HTC20NRS-G - Synqor

IQ4H150HTC20NRS-G Details

• Manufacturer Part Number:

  IQ4H150HTC20NRS-G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Package Description:

  1/2 BRICK PACKAGE-11

• Pin Count:

  9

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• YTEOL:

  7

• Additional Feature:

  AIR FLOW RATE=300 LFM

• Analog IC - Other Type:

  DC-DC UNREGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CSA, EN, UL, CE

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  89%

• Input Voltage-Max:

  425 V

• Input Voltage-Min:

  180 V

• Input Voltage-Nom:

  385 V

• JESD-30 Code:

  R-XDMA-P11

• JESD-609 Code:

  e3

• Length:

  63.14 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  11

• Output Current-Max:

  20 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  12 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OUTPUT OVER VOLTAGE

• Qualification Status:

  Not Qualified

• Ripple Voltage (Main Out):

  0.084 Vrms

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  590 kHz

• Technology:

  HYBRID

• Terminal Finish:

  MATTE TIN OVER NICKEL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  300 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.44 s

• Width:

  60.6 mm
