IQ64120QGC04NRS-G - Synqor

IQ64120QGC04NRS-G Details

• Manufacturer Part Number:

  IQ64120QGC04NRS-G

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  MODULE

• Package Description:

  ROHS COMPLIANT, QUARTER BRICK PACKAGE-8

• Pin Count:

  8

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• Manufacturer:

  SynQor

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CSA, CE, EN, UL

• Efficiency (Main Output):

  87%

• Input Voltage-Max:

  135 V

• Input Voltage-Min:

  18 V

• Input Voltage-Nom:

  64 V

• JESD-30 Code:

  R-XDMA-P8

• JESD-609 Code:

  e3

• Length:

  60.6 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  0.3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  4 A

• Output Voltage-Max:

  13.2 V

• Output Voltage-Min:

  9.6 V

• Output Voltage-Nom:

  12 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,8LEAD,2

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER CURRENT; OVER TEMPERATURE; REVERSE POLARITY; SHORT CIRCUIT; UVP

• Ripple Voltage (Main Out):

  0.04 Vrms

• Seated Height-Max:

  13.33 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  48 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.01 s

• Width:

  39.01 mm
