iQL48011A280V-009-R - TDK Lambda

iQL48011A280V-009-R Details

• Manufacturer Part Number:

  IQL48011A280V-009-R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  XMA,

• Reach Compliance Code:

  Compliant

• ECCN Code:

  EAR99

• Manufacturer:

  TDK-Lambda Corporation

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, CSA, EN, IEC, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  92.5%

• Input Voltage-Max:

  75 V

• Input Voltage-Min:

  36 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  R-XXMA-X8

• Line Regulation-Max:

  0.028%

• Load Regulation-Max:

  0.357%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  115 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  11 A

• Output Voltage-Max:

  30.8 V

• Output Voltage-Min:

  22.4 V

• Output Voltage-Nom:

  28 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  XMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER LOAD; OVER VOLTAGE; THERMAL

• Ripple Voltage (Main Out):

  0.17675 Vrms

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  UNSPECIFIED

• Terminal Position:

  UNSPECIFIED

• Total Power Output-Max:

  308 W

• Trim/Adjustable Output:

  YES
