IR1167BSTRPBF - Infineon

Description: Infineon IR1167BSTRPBF MOSFET Power Driver, 7A 8-Pin, SOIC

Download IR1167BSTRPBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
IR1167BSTRPBF - Infineon PCB footprint - Small Outline Packages - Small Outline Packages - IR1167BSTRPBF
click to zoom
3D Models
IR1167BSTRPBF - Infineon  - 3D model - Small Outline Packages - IR1167BSTRPBF
click to zoom

IR1167BSTRPBF Details

  • Manufacturer Part Number:

    IR1167BSTRPBF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    LEAD FREE, MS-012AA, SOIC-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    52 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • High Side Driver:

    NO

  • Input Characteristics:

    GATED SCHMITT TRIGGER

  • Interface IC Type:

    BUFFER OR INVERTER BASED MOSFET DRIVER

  • JESD-30 Code:

    R-PDSO-G8

  • JESD-609 Code:

    e3

  • Length:

    4.9 mm

  • Moisture Sensitivity Level:

    2

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -25 °C

  • Output Characteristics:

    STANDARD

  • Output Peak Current Limit-Nom:

    7 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max:

    80 mA

  • Supply Voltage-Max:

    18 V

  • Supply Voltage-Min:

    12 V

  • Supply Voltage-Nom:

    15 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Matte Tin (Sn) - with Nickel (Ni) barrier

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Turn-off Time:

    0.065 µs

  • Turn-on Time:

    0.08 µs

  • Width:

    3.9 mm

IR1167BSTRPBF Frequently Asked Questions (FAQs)

  • A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. The device should be placed near a heat sink or a thermal pad to dissipate heat efficiently.
  • Ensure proper heat sinking, use a thermally conductive material for the PCB, and consider using a thermal interface material (TIM) between the device and the heat sink. Also, follow the recommended operating temperature range and derating guidelines.
  • Monitor the device's temperature, voltage, and current. Implement over-temperature protection (OTP), over-voltage protection (OVP), and over-current protection (OCP) to prevent damage and ensure reliable operation.
  • Adjust the gate resistor value, gate voltage, and dead-time settings based on the specific requirements of your application. Consult the datasheet and application notes for guidance on optimizing performance.
