IR2161PBF - Infineon

Description: Infineon IR2161PBF, Lighting Ballast Driver Half Bridge, 16.5V 8-Pin, PDIP

Download IR2161PBF Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
IR2161PBF - Infineon PCB footprint - Dual-In-Line Packages - Dual-In-Line Packages - 8-Lead PDIP
click to zoom
3D Models
IR2161PBF - Infineon  - 3D model - Dual-In-Line Packages - 8-Lead PDIP
click to zoom

IR2161PBF Details

  • Manufacturer Part Number:

    IR2161PBF

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Obsolete

  • Package Description:

    PLASTIC, DIP-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    4 Weeks

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    0

  • High Side Driver:

    YES

  • Input Characteristics:

    STANDARD

  • Interface IC Type:

    HALF BRIDGE BASED MOSFET DRIVER

  • JESD-30 Code:

    R-PDIP-T8

  • JESD-609 Code:

    e3

  • Length:

    9.88 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -25 °C

  • Output Characteristics:

    STANDARD

  • Output Peak Current Limit-Nom:

    0.5 A

  • Output Polarity:

    TRUE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    DIP

  • Package Shape:

    RECTANGULAR

  • Package Style:

    IN-LINE

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    5.33 mm

  • Supply Current-Max:

    10 mA

  • Supply Voltage-Max:

    16.5 V

  • Supply Voltage-Min:

    10.8 V

  • Supply Voltage-Nom:

    14 V

  • Supply Voltage1-Max:

    600 V

  • Supply Voltage1-Min:

    -1 V

  • Supply Voltage1-Nom:

    14 V

  • Surface Mount:

    NO

  • Terminal Finish:

    MATTE TIN

  • Terminal Form:

    THROUGH-HOLE

  • Terminal Pitch:

    2.54 mm

  • Terminal Position:

    DUAL

  • Turn-off Time:

    0.14 µs

  • Turn-on Time:

    0.25 µs

  • Width:

    7.62 mm

IR2161PBF Frequently Asked Questions (FAQs)

  • The maximum operating frequency of the IR2161PBF is 100 kHz, but it can be operated up to 200 kHz with reduced performance.
  • To ensure proper biasing, connect the VCC pin to a stable 15V power supply, and the GND pin to a solid ground plane. Also, decouple the VCC pin with a 10uF capacitor to reduce noise.
  • For optimal performance, use a 4-layer PCB with a solid ground plane, and route the high-frequency signals (e.g., IN and OUT) on the top layer, keeping them short and away from noise sources.
  • Use a voltage regulator to limit the input voltage to 15V, and add a current-limiting resistor in series with the output to prevent overcurrent. Also, consider adding TVS diodes for overvoltage protection.
  • Use a heat sink with a thermal resistance of 10°C/W or lower, and ensure good airflow around the device. Also, consider using a thermal interface material to improve heat transfer.
