IRE-24/5-Q12NF-C - Murata Electronics

IRE-24/5-Q12NF-C Details

• Manufacturer Part Number:

  IRE-24/5-Q12NF-C

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  1/8 BRICK PACKAGE-8

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• Factory Lead Time:

  36 Weeks

• Date Of Intro:

  2020-06-05

• Manufacturer:

  Murata Manufacturing Co Ltd

• YTEOL:

  7

• Additional Feature:

  UNDER VOLTAGE

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN; CSA; C-UL-US; EN; IEC; UL

• Efficiency (Main Output):

  92%

• Input Voltage-Max:

  36 V

• Input Voltage-Min:

  9 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PDFM-P8

• Length:

  61.2 mm

• Line Regulation-Max:

  0.4%

• Load Regulation-Max:

  0.4%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  5 A

• Output Voltage-Max:

  26.4 V

• Output Voltage-Min:

  19.2 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DFM

• Package Equivalence Code:

  MODULE,8LEAD,2

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Packing Method:

  TRAY

• Protections:

  OVER CURRENT; OVER TEMPERATURE; OVER VOLTAGE; REVERSE POLARITY; SCP

• Ripple Voltage (Main Out):

  0.0848 Vrms

• Screening Level:

  UL 62368-1

• Seated Height-Max:

  13.34 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  120 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.05 s

• Width:

  36.8 mm
