IS29GL256-70DLEB - Integrated Silicon Solution Inc.

IS29GL256-70DLEB Details

• Manufacturer Part Number:

  IS29GL256-70DLEB

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  BGA-64

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.32.00.51

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Integrated Silicon Solution Inc

• YTEOL:

  4.7

• Access Time-Max:

  70 ns

• JESD-30 Code:

  S-PBGA-B64

• JESD-609 Code:

  e3

• Length:

  9 mm

• Memory Density:

  268435456 bit

• Memory IC Type:

  FLASH

• Memory Width:

  1

• Number of Functions:

  1

• Number of Terminals:

  64

• Number of Words:

  268435456 words

• Number of Words Code:

  256000000

• Operating Mode:

  ASYNCHRONOUS

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  256MX1

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  LBGA

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, LOW PROFILE

• Parallel/Serial:

  PARALLEL

• Programming Voltage:

  3 V

• Seated Height-Max:

  1.4 mm

• Supply Voltage-Max (Vsup):

  3.6 V

• Supply Voltage-Min (Vsup):

  2.7 V

• Supply Voltage-Nom (Vsup):

  3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  BALL

• Terminal Pitch:

  1 mm

• Terminal Position:

  BOTTOM

• Width:

  9 mm
