IS31LT3353-SDLS4-TR - Lumissil Microsystems

IS31LT3353-SDLS4-TR Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  The datasheet provides general guidelines, but Lumissil recommends a 2oz copper thickness, 1.6mm PCB thickness, and a thermal pad connected to a large copper area on the PCB. A dedicated application note or layout guide can be requested from Lumissil's support team.
• How do I adjust the LED current accuracy?
  The IS31LT3353 has an internal current sense resistor. To adjust the LED current accuracy, you can use an external resistor (RSET) to fine-tune the current sense voltage. Consult the datasheet's equation (6) to calculate the required RSET value.
• What is the maximum allowable voltage on the EN pin?
  Although the datasheet specifies a maximum EN pin voltage of 6V, Lumissil recommends limiting it to 5.5V to ensure reliable operation and prevent damage to the internal voltage regulator.
• Can I use a lower value for the input capacitor (CIN)?
  While the datasheet recommends a 10uF input capacitor, a lower value can be used depending on the specific application. However, this may affect the device's power-on reset (POR) timing and stability. Consult Lumissil's support team for guidance on capacitor selection.
• How do I ensure electromagnetic compatibility (EMC) in my design?
  Follow the datasheet's layout guidelines, use a shielded inductor, and ensure proper PCB routing to minimize EMI. Additionally, consider using EMI filters or common-mode chokes to further reduce emissions.
