The recommended operating voltage range for the ISD2115AYYIR is 2.7V to 3.6V.
A simple reset circuit can be implemented using a 10kΩ resistor, a 10μF capacitor, and a diode. Connect the resistor and capacitor in series between VCC and RST, and the diode between RST and GND.
The maximum clock frequency supported by the ISD2115AYYIR is 16 MHz.
To configure the ISD2115AYYIR for low-power operation, set the PWRDN bit in the Power Management Control Register (PMC) to 1. This will put the device into power-down mode, reducing power consumption.
The internal oscillator is used to generate a clock signal for the device, eliminating the need for an external clock source. It can be used as a clock source for the CPU, peripherals, and other internal circuits.
