ISL28190FRUZ-T7 - Renesas Electronics

ISL28190FRUZ-T7 Details

• Manufacturer Part Number:

  ISL28190FRUZ-T7

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  1.60 X 1.60 MM, ROHS COMPLIANT, PLASTIC, MO-229, UTQFN-6

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Date Of Intro:

  2017-11-08

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  18 µA

• Bandwidth (3dB)-Nom:

  171000 MHz

• Bias Current-Max (IIB) @25C:

  16 µA

• Common-mode Reject Ratio-Min:

  103 dB

• Common-mode Reject Ratio-Nom:

  78 dB

• Frequency Compensation:

  NO

• Input Offset Current-Max (IIO):

  0.9 µA

• Input Offset Voltage-Max:

  900 µV

• JESD-30 Code:

  S-PDSO-N6

• Length:

  1.6 mm

• Low-Bias:

  NO

• Low-Offset:

  YES

• Micropower:

  NO

• Number of Functions:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HVSON

• Package Equivalence Code:

  SOLCC6,.06SQ,20

• Package Shape:

  SQUARE

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE

• Packing Method:

  TR, 7 INCH

• Power:

  NO

• Programmable Power:

  NO

• Seated Height-Max:

  0.55 mm

• Slew Rate-Min:

  25 V/us

• Slew Rate-Nom:

  50 V/us

• Supply Current-Max:

  13 mA

• Supply Voltage Limit-Max:

  5.5 V

• Supply Voltage-Nom (Vsup):

  5 V

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  DUAL

• Voltage Gain-Min:

  31622

• Wideband:

  NO

• Width:

  1.6 mm
