ISL74420M30NZ - Renesas Electronics

Description: Radiation Tolerant Quad Adjustable Clock Fanout for Power Management ICs, ±100mA, 50MHz, -55°C to +125°C

Download ISL74420M30NZ Model

Schematic
symbols

PCB
footprints

3D
models

Alert me if there are changes to this ISL74420M30NZ model

Email notifications will be applied after download.

Send part feedback

Symbol

ISL74420M30NZ - Renesas Electronics - PCB symbol

PCB Footprints

ISL74420M30NZ - Renesas Electronics PCB footprint - Quad Flat Packages - Quad Flat Packages - Q48.7x7C-1

3D Models

ISL74420M30NZ - Renesas Electronics - 3D model - Quad Flat Packages - Q48.7x7C-1

Datasheet Download Datasheet
Stock & Prices Price & Stock for ISL74420M30NZ
Part Number ISL74420M30NZ
Manufacturer Renesas Electronics
Pin Count 49
Part Category Integrated Circuit
Package Category Quad Flat Packages
Footprint Name Quad Flat Packages - Q48.7x7C-1
Released Date Feb 5, 2025
Last Modified Date Feb 5, 2025 3:07 PM UTC
Pinout / Pin List Click Here (Member Only)

ISL74420M30NZ Details

Manufacturer Part Number:
ISL74420M30NZ
Manufacturer:
Renesas Electronics Corporation

Trust Checks

Manufacturer Collaborated

System Verified

Community Approved

ISL74420M30NZ Overview

Use the download button to access the ISL74420M30NZ schematic symbol, PCB footprint, and 3D model.

To find more CAD model downloads similar to this part, try a partial part number search, like ISL74, or try a keyword search, such as MOSFET Drivers
