ISL8024AIRTAJZ - Renesas Electronics

Description: The ISL8024A is a highly efficient, monolithic, synchronous step-down DC/DC converter that can deliver 4A of continuous output current from a 2.7V to 5.5V input supply. The device uses current mode control architecture to deliver very low-duty cycle operation at high frequency with fast transient response and excellent loop stability. It has an adjustable frequency from 500kHz to 4MHz with the default at 2MHz (ISL8023A/24A).The ISL8023 and ISL8024 integrate a very low On-resistance P-Channel (45mΩ) high sid
