ISL8200AMMRZ - Renesas Electronics

ISL8200AMMRZ Details

• Manufacturer Part Number:

  ISL8200AMMRZ

• Brand Name:

  Renesas

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  Module

• Package Description:

  QFN-23

• Pin Count:

  23

• Manufacturer Package Code:

  L23.15X15

• ECCN Code:

  EAR99

• Date Of Intro:

  2017-12-21

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  ALSO OPERATES IN ADJUSTABLE MODE FROM 0.6 TO 6V

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Control Mode:

  VOLTAGE-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  20 V

• Input Voltage-Min:

  3 V

• Input Voltage-Nom:

  4.5 V

• JESD-30 Code:

  S-PQCC-N23

• JESD-609 Code:

  e3

• Length:

  15 mm

• Moisture Sensitivity Level:

  3

• Number of Functions:

  1

• Number of Terminals:

  23

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  10 A

• Output Voltage-Max:

  6 V

• Output Voltage-Min:

  0.6 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QCCN

• Package Equivalence Code:

  LCC23,.62SQ,43

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER

• Seated Height-Max:

  2.4 mm

• Surface Mount:

  YES

• Switching Frequency-Max:

  700 kHz

• Technology:

  MOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  1.1 mm

• Terminal Position:

  QUAD

• Width:

  15 mm
