The recommended PCB footprint for IXFH26N50 is a standard SOT-227 package with a minimum pad size of 3.5mm x 2.5mm and a maximum pad size of 5.5mm x 4.5mm. It's recommended to consult the Littelfuse application note AN9313 for more detailed information on PCB layout and thermal considerations.
Yes, IXFH26N50 is a high-reliability device that meets the requirements of AEC-Q101, a standard for automotive-grade components. It's suitable for use in high-reliability applications such as automotive, industrial, and medical devices.
To ensure proper soldering, follow the recommended soldering profile of 260°C for 10 seconds. Use a solder with a melting point of 217°C to 221°C, and apply a solder flux that is compatible with the device's lead finish. Avoid overheating or applying excessive force to the device during soldering.
The maximum allowed voltage derating for IXFH26N50 is 80% of the rated voltage. This means that if the device is rated for 500V, the maximum allowed voltage derating would be 400V. Exceeding this derating may affect the device's reliability and lifespan.
Yes, IXFH26N50 can be used in a parallel configuration to increase current handling. However, it's essential to ensure that the devices are properly matched and that the PCB layout is designed to minimize current imbalance and thermal mismatch between the devices.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
IXFH26N50 Overview
Use the download button to access the IXFH26N50 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like IXFH2,
or try a keyword search, such as Power Field-Effect Transistors
