IXFK20N120 - LITTELFUSE

IXFK20N120 Details

• Manufacturer Part Number:

  IXFK20N120

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  TO-264AA, 3 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Avalanche Energy Rating (Eas):

  2000 mJ

• Case Connection:

  DRAIN

• Configuration:

  SINGLE WITH BUILT-IN DIODE

• DS Breakdown Voltage-Min:

  1200 V

• Drain Current-Max (ID):

  20 A

• Drain-source On Resistance-Max:

  0.75 Ω

• FET Technology:

  METAL-OXIDE SEMICONDUCTOR

• JEDEC-95 Code:

  TO-264AA

• JESD-30 Code:

  R-PSFM-T3

• JESD-609 Code:

  e1

• Number of Elements:

  1

• Number of Terminals:

  3

• Operating Mode:

  ENHANCEMENT MODE

• Operating Temperature-Max:

  150 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  N-CHANNEL

• Pulsed Drain Current-Max (IDM):

  80 A

• Qualification Status:

  Not Qualified

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Silver/Copper (Sn96.5Ag3.0Cu0.5)

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  10

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON
