J107F1CS205VDC.45 - CIT Relay & Switch

J107F1CS205VDC.45 Details

• Manufacturer Part Number:

  J107F1CS205VDC.45

• Part Life Cycle Code:

  Contact Manufacturer

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Manufacturer:

  CIT Relay & Switch

• Body Breadth:

  15.5 mm

• Body Height:

  15.3 mm

• Body Length or Diameter:

  19 mm

• Coil Power:

  450 mW

• Coil Resistance:

  56 Ω

• Coil Voltage-Nom:

  5 V

• Contact (AC) Max Rating R Load:

  20A@125VAC

• Contact Current(AC)-Max:

  20 A

• Contact Current(DC)-Max:

  20 A

• Contact (DC) Max Rating R Load:

  20A@16VDC

• Contact Resistance:

  50 mΩ

• Contact Voltage(AC)-Max:

  125 V

• Contact Voltage(DC)-Max:

  16 V

• Electrical Life:

  100000 Cycle(s)

• Operate Time:

  10 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Physical Dimension:

  19mm x 15.5mm x 15.3mm

• Relay Function:

  SPDT

• Release Time:

  5 ms

• Terminal Length:

  0.004000508001016002 inch
