J412DD-26M - Teledyne Technologies

J412DD-26M Details

• Manufacturer Part Number:

  J412DD-26M

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  Teledyne Technologies Inc

• Body Height:

  6.86 mm

• Body Length or Diameter:

  9.4 mm

• Coil Operate Voltage(DC):

  19 V

• Coil Release Voltage(DC):

  1.4 V

• Coil Resistance:

  1560 Ω

• Coil Voltage(DC)-Max:

  32 V

• Coil Voltage-Nom:

  26.5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  0.25A@115VAC

• Contact Current(AC)-Max:

  0.25 A

• Contact Current(DC)-Max:

  1 A

• Contact (DC) Max Rating R Load:

  1A@28VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  115 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Input Switching Control Type:

  Random

• Insulation Resistance:

  10000000000 Ω

• Number of Terminals:

  9

• Operate Time:

  2 ms

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Physical Dimension:

  9.4mm x 6.86mm

• Relay Action:

  LATCHED

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Release Time:

  4 ms

• Sealing:

  HERMETICAL

• Terminal Length:

  0.018999237998476 inch

• Termination Type:

  SOLDER
