JANTX2N6649 - Microchip

JANTX2N6649 Details

• Manufacturer Part Number:

  JANTX2N6649

• Part Life Cycle Code:

  Active

• Package Description:

  TO-3, 2 PIN

• Country Of Origin:

  Philippines

• ECCN Code:

  EAR99

• HTS Code:

  8541.29.00.95

• Manufacturer:

  Microchip Technology Inc

• YTEOL:

  23

• Case Connection:

  COLLECTOR

• Collector Current-Max (IC):

  10 A

• Collector-Emitter Voltage-Max:

  60 V

• Configuration:

  SINGLE

• DC Current Gain-Min (hFE):

  100

• JEDEC-95 Code:

  TO-3

• JESD-30 Code:

  O-MBFM-P2

• JESD-609 Code:

  e0

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  175 °C

• Package Body Material:

  METAL

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Polarity/Channel Type:

  NPN

• Qualification Status:

  Qualified

• Reference Standard:

  MIL-19500/527B

• Surface Mount:

  NO

• Terminal Finish:

  Tin/Lead (Sn/Pb)

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Transistor Element Material:

  SILICON
