JHL0612D15 - XP POWER

JHL0612D15 Details

• Manufacturer Part Number:

  JHL0612D15

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DIP-24/9

• ECCN Code:

  EAR99

• Manufacturer:

  XP Power

• YTEOL:

  6

• Additional Feature:

  IT ALSO HAS -15 V OUTPUT VOLTAGE 2

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  ANSI, CSA, EN, IEC, UL

• Efficiency (Main Output):

  83%

• Input Voltage-Max:

  17 V

• Input Voltage-Min:

  10 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-XDMA-P9

• Length:

  31.75 mm

• Line Regulation-Max:

  0.3%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  9

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -20 °C

• Output Current-Max:

  0.2 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  13.5 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE; OVER LOAD; SHORT CIRCUIT

• Screening Level:

  IEC 60601-1, Two MOPP

• Seated Height-Max:

  10.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  6 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.007 s

• Width:

  20.32 mm
