JMAWDG-18XP - TE Connectivity

JMAWDG-18XP Details

• Manufacturer Part Number:

  JMAWDG-18XP

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Coil Power:

  368 mW

• Coil Resistance:

  880 Ω

• Coil Voltage(DC)-Max:

  18 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact Voltage(AC)-Max:

  28 V

• Contact Voltage(DC)-Max:

  28 V

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT-CO

• Relay Type:

  POWER/SIGNAL RELAY

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT
