JMSCD-5XM - TE Connectivity

JMSCD-5XM Details

• Manufacturer Part Number:

  JMSCD-5XM

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Factory Lead Time:

  28 Weeks, 3 Days

• Manufacturer:

  TE Connectivity

• Additional Feature:

  WITH COIL SUPPRESSION DIODE

• Coil Current(DC)-Max:

  0.05 A

• Coil Power:

  250 mW

• Coil Resistance:

  100 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  1 A

• Contact Current(DC)-Max:

  1 A

• Contact Voltage(AC)-Max:

  28 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Mounting Feature:

  PANEL MOUNT

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -65 °C

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT-CO

• Relay Type:

  POWER/SIGNAL RELAY

• Sealing:

  HERMETICALLY SEALED

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT
