JS203011SCQN - LITTELFUSE

JS203011SCQN Details

• Manufacturer Part Number:

  JS203011SCQN

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.50

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  6

• Actuator Color:

  BLACK

• Actuator Length:

  0.079 inch

• Actuator Material:

  NYLON

• Actuator Type:

  SLIDE

• Additional Feature:

  ROHS COMPLIANT

• Body Breadth:

  3.5052 mm

• Body Height:

  3.5052 mm

• Body Length or Diameter:

  13.0048 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Resistance:

  0.07 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  15000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  SILVER

• Housing Material:

  NYLON

• Illumination:

  NON-ILLUMINATED

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  3

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  TR, 13 INCH

• Solderability:

  REFLOW

• Surface Mount:

  NO

• Switch Action:

  LATCHED

• Switch Function:

  DP3T

• Switch Type:

  SLIDE SWITCH

• Terminal Finish:

  Silver (Ag)

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
