JSPHS-661+ - Mini-Circuits

JSPHS-661+ Details

• Manufacturer Part Number:

  JSPHS-661+

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT PACKAGE, CASE BK276, 14 PIN

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  20 dBm

• Insertion Loss-Max:

  2.5 dB

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  14

• Operating Frequency-Max:

  660 MHz

• Operating Frequency-Min:

  400 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  METAL

• Phase Shift-Min:

  180 deg

• RF/Microwave Device Type:

  PHASE SHIFTER

• Surface Mount:

  YES

• VSWR-Max:

  2.2
