JTOS-850VW - Mini-Circuits

JTOS-850VW Details

• Manufacturer Part Number:

  JTOS-850VW

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Package Description:

  CASE BK377, 14 PIN

• Manufacturer:

  Mini-Circuits

• YTEOL:

  5.59

• Control Voltage-Max:

  18 V

• Control Voltage-Min:

  0.5 V

• JESD-609 Code:

  e0

• Modulation Sensitivity:

  80 MHz/V

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  14

• Offset Frequency:

  1 kHz

• Operating Frequency-Max:

  850 MHz

• Operating Frequency-Min:

  400 MHz

• Operating Frequency-Nom:

  850 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -55 °C

• Oscillator Type:

  VOLTAGE CONTROLLED OSCILLATOR

• Output Power:

  6 dBm

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SMDIP14,.5

• Phase Noise:

  -74 dBc/Hz

• Physical Dimension:

  20.32mm x 12.83mm x 6.35mm

• Qualification Status:

  Not Qualified

• Supply Current-Max:

  20 mA

• Supply Voltage-Nom:

  5 V

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Lead (Sn/Pb)
