JWK1024S24 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  XP Power recommends a PCB layout with a large copper area connected to the module's thermal pad to dissipate heat efficiently. A minimum of 1 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• How do I ensure the module's reliability in high-vibration environments?
  To ensure reliability in high-vibration environments, XP Power recommends securing the module to the PCB using screws or adhesive, and ensuring that the PCB is properly secured to the chassis or enclosure. Additionally, the module's pins should be soldered securely to the PCB to prevent damage from vibration.
• What is the maximum allowable capacitance for the output filter?
  The maximum allowable capacitance for the output filter is 10uF. Exceeding this value may cause instability or oscillation in the output voltage.
• Can I use the JWK1024S24 in a redundant configuration?
  Yes, the JWK1024S24 can be used in a redundant configuration to achieve high availability and reliability. However, XP Power recommends consulting with their application engineers to ensure proper design and implementation of the redundant system.
• What is the recommended input fuse rating for the module?
  XP Power recommends using a fuse with a rating of 2A to 5A, depending on the input voltage and current requirements of the system. The fuse should be selected to protect the module from overcurrent conditions.
