K10P-11D55-110 - TE Connectivity

K10P-11D55-110 Details

• Manufacturer Part Number:

  K10P-11D55-110

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.50

• Factory Lead Time:

  18 Weeks, 2 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Body Breadth:

  21.8 mm

• Body Height:

  35.56 mm

• Body Length or Diameter:

  28.2 mm

• Coil Current(DC)-Max:

  0.008 A

• Coil Operate Voltage(DC):

  82.5 V

• Coil Power:

  1100 mW

• Coil Release Voltage(DC):

  11 V

• Coil Resistance:

  11000 Ω

• Coil Voltage(DC)-Max:

  110 V

• Coil Voltage-Nom:

  240 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  15A@120VAC

• Contact Current(AC)-Max:

  15 A

• Contact Current(DC)-Max:

  15 A

• Contact (DC) Max Rating R Load:

  15A@30VDC

• Contact Resistance:

  100 mΩ

• Contact Voltage(AC)-Max:

  120 V

• Contact Voltage(DC)-Max:

  30 V

• Contact/Output Supply Type:

  AC

• Dielectric Strength Between Coil and Contacts:

  1500 Vrms

• Dielectric Strength Between Open Contacts:

  1000 Vrms

• Electrical Life:

  10000000 Cycle(s)

• End Contact Material:

  SILVER CADMIUM OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  13 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -45 °C

• Packing Method:

  BOX; TRAY

• Physical Dimension:

  28.2mm x 21.8mm x 34.9mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  6 ms

• Sealing:

  DUST PROOF

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  51 g
