K12PLGN15NLV306 - LITTELFUSE

K12PLGN15NLV306 Details

• Manufacturer Part Number:

  K12PLGN15NLV306

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  France

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  7

• Actuator Travel:

  1 mm

• Actuator Type:

  BUTTON TYPE

• Body Height:

  11 mm

• Body Length or Diameter:

  12 mm

• Circuit Configuration:

  1X1

• Contact Bounce Time-Max:

  1 ms

• Contact Current(AC)-Max:

  0.1 A

• Contact Current(DC)-Max:

  0.1 A

• Contact (DC) Max Power Rating R Load:

  3VA@30VDC

• Contact (DC) Max Rating R Load:

  0.1A@30VDC

• Contact Function:

  ON-OFF

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  30 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  1000000 Cycle(s)

• Illumination:

  GREEN LED

• Insulation Resistance:

  10000000000 Ω

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Switches:

  1

• Operating Force-Max:

  5 N

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  5

• Packing Method:

  BULK

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Length:

  0.11 inch

• Termination Type:

  SOLDER
