KAE04LGGR - E-Switch

KAE04LGGR Details

• Manufacturer Part Number:

  KAE04LGGR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Vietnam

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• Actuator Length:

  0.028 inch

• Actuator Type:

  SLIDE

• Body Breadth:

  6.2992 mm

• Body Height:

  3.7592 mm

• Body Length or Diameter:

  11.2014 mm

• Center Contact Material:

  COPPER ALLOY

• Center Contact Plating:

  GOLD

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VAC V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  COPPER ALLOY

• End Contact Plating:

  GOLD

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT-STRAIGHT

• Number of Positions:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Surface Mount:

  NO

• Switch Action:

  HORIZONTAL

• Switch Function:

  SPST

• Terminal Finish:

  Gold (Au)

• Terminal Material:

  BRASS

• Termination Type:

  SOLDER
