KAS1104ET - E-Switch

KAS1104ET Details

• Manufacturer Part Number:

  KAS1104ET

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• YTEOL:

  6.7

• Actuator Length:

  0.039 inch

• Actuator Type:

  SLIDE TYPE

• Body Breadth:

  9.906 mm

• Body Height:

  5.9944 mm

• Body Length or Diameter:

  11.5316 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  GOLD OVER NICKEL

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  500VRMS V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  GOLD OVER NICKEL

• Insulation Resistance:

  100000000 Ω

• JESD-609 Code:

  e4

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Number of Positions:

  4

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  8

• Surface Mount:

  NO

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Finish:

  Gold/Nickel (Au/Ni)

• Terminal Length:

  0.126 inch

• Terminal Material:

  PHOSPHOR BRONZE

• Termination Type:

  SOLDER
