KAS2106ET - E-Switch

KAS2106ET Details

• Manufacturer Part Number:

  KAS2106ET

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.70.00

• Manufacturer:

  E-Switch Inc

• YTEOL:

  5.8

• Actuator Length:

  0.039 inch

• Actuator Type:

  SLIDE TYPE

• Additional Feature:

  EXTENDED ACTUATOR

• Body Breadth:

  9.906 mm

• Body Height:

  8.7376 mm

• Body Length or Diameter:

  16.6116 mm

• Center Contact Material:

  PHOSPHOR BRONZE

• Center Contact Plating:

  SILVER

• Contact Current(DC)-Max:

  0.025 A

• Contact (DC) Max Rating R Load:

  0.025A@24VDC

• Contact Resistance:

  0.05 mΩ

• Contact Voltage(DC)-Max:

  24 V

• Dielectric Withstand Volts:

  1000VRMS V

• Electrical Life:

  2000 Cycle(s)

• End Contact Material:

  PHOSPHOR BRONZE

• End Contact Plating:

  SILVER

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Positions:

  6

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  12

• Surface Mount:

  NO

• Switch Function:

  SPST

• Switch Type:

  SLIDE DIP SWITCH

• Terminal Length:

  0.114 inch

• Terminal Material:

  PHOSPHOR BRONZE

• Termination Type:

  SOLDER
