KCDX-5S-N - Kycon

KCDX-5S-N Details

• Manufacturer Part Number:

  KCDX-5S-N

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Kycon Inc

• YTEOL:

  7

• Additional Feature:

  ROHS COMPLIANT

• Body Breadth:

  0.768 inch

• Body Depth:

  0.748 inch

• Body Length:

  0.827 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  DIN CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Tin (Sn)

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  60 mΩ

• DIN Conformance:

  YES

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  5000 Cycles

• EMI Shielded:

  NO

• IEC Conformance:

  NO

• Insulation Resistance:

  100000000 Ω

• Insulator Color:

  BLACK

• JESD-609 Code:

  e3

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  2 A

• Reference Standard:

  UL, CSA

• Shell Finish:

  NICKEL

• Shell Material:

  PHOSPHOR BRONZE

• Terminal Length:

  0.157 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  5
