KDMIX-SL1-NS-WS-B15 - Kycon

KDMIX-SL1-NS-WS-B15 Details

• Manufacturer Part Number:

  KDMIX-SL1-NS-WS-B15

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.30

• Manufacturer:

  Kycon Inc

• Board Mounting Option:

  PEG

• Body Breadth:

  0.646 inch

• Body Length:

  0.256 inch

• Body/Shell Style:

  RECEPTACLE

• Connector Type:

  DISPLAYPORT CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  NOT APPLICABLE

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Style:

  USB SER A FLAT

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  10000 Cycles

• Insulation Resistance:

  100000000 Ω

• Insulator Material:

  POLYETHYLENE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number Of Connectors:

  ONE

• Number of Ports:

  1

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• PCB Contact Pattern:

  STAGGERED

• PCB Contact Row Spacing:

  1.143 mm

• Plating Thickness:

  15u inch

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  0.5 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  STAINLESS STEEL

• Terminal Length:

  0.091 inch

• Terminal Pitch:

  0.9906 mm

• Termination Type:

  SOLDER

• Total Number of Contacts:

  19
