KMDGX-6S-AS - Kycon

KMDGX-6S-AS Details

• Manufacturer Part Number:

  KMDGX-6S-AS

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Kycon Inc

• YTEOL:

  7.5

• Additional Feature:

  ROHS COMPLIANT

• Board Mounting Option:

  SPLIT BOARD LOCK

• Body Breadth:

  0.512 inch

• Body Depth:

  0.508 inch

• Body Length:

  0.551 inch

• Body/Shell Style:

  PLUG

• Connector Type:

  MINI DIN CONNECTOR

• Contact Finish Mating:

  NOT SPECIFIED

• Contact Finish Termination:

  Gold (Au)

• Contact Gender:

  FEMALE

• Contact Material:

  NOT SPECIFIED

• Contact Resistance:

  60 mΩ

• Contact Style:

  RND PIN-SKT

• DIN Conformance:

  YES

• Dielectric Withstanding Voltage:

  700VAC V

• Durability:

  500 Cycles

• EMI Shielded:

  YES

• IEC Conformance:

  NO

• Insulation Resistance:

  500000000 Ω

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE/POLYETHYLENE

• JESD-609 Code:

  e4

• MIL Conformance:

  NO

• Mounting Option 1:

  LOCKING

• Mounting Style:

  RIGHT ANGLE

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  80 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Plating Thickness:

  FLASH inch

• Polarization Key:

  POLARIZED

• Rated Current (Signal):

  2 A

• Reference Standard:

  UL

• Shell Finish:

  NICKEL

• Shell Material:

  BRASS

• Terminal Length:

  0.125 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  6
