KMDVLX-5S-N-1 - Kycon

KMDVLX-5S-N-1 Details

• Manufacturer Part Number:

  KMDVLX-5S-N-1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8536.69.40.20

• Manufacturer:

  Kycon Inc

• Board Mounting Option:

  SOLDER HOLDING FLANGE

• Body Depth:

  0.374 inch

• Connector Type:

  MINI DIN CONNECTOR

• Contact Gender:

  FEMALE

• Contact Resistance:

  30 mΩ

• Contact Style:

  RND PIN-SKT

• Dielectric Withstanding Voltage:

  500VAC V

• Durability:

  5000 Cycles

• EMI Shielded:

  YES

• Insertion Force-Max:

  29.42 N

• Insulation Resistance:

  50000000 Ω

• Insulator Color:

  BLACK

• Insulator Material:

  POLYBUTYLENE TEREPHTHALATE/POLYETHYLENE

• Mounting Option 1:

  LOCKING

• Mounting Style:

  STRAIGHT

• Mounting Type:

  BOARD

• Number of Ports:

  1

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Option:

  GENERAL PURPOSE

• Polarization Key:

  POLARIZED HOUSING

• Rated Current (Signal):

  2 A

• Reference Standard:

  CSA,CUL,UL

• Shell Finish:

  MATTE TIN

• Shell Material:

  BRASS

• Terminal Length:

  0.138 inch

• Termination Type:

  SOLDER

• Total Number of Contacts:

  5
