KP236N6165 - Infineon

Description: Pressure Sensor 8.7PSI ~ 23.93PSI (60kPa ~ 165kPa) Absolute 0.1 V ~ 4.85 V 8-SMD Module

Download KP236N6165 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
KP236N6165 - Infineon PCB footprint - Other - Other - PG-DSOF-8-16_2024
click to zoom
3D Models
KP236N6165 - Infineon  - 3D model - Other - PG-DSOF-8-16_2024
click to zoom

KP236N6165 Details

  • Manufacturer Part Number:

    KP236N6165

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SMD-8

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00

  • Manufacturer:

    Infineon Technologies AG

  • YTEOL:

    11

  • Additional Feature:

    AEC-Q100

  • Body Breadth:

    7 mm

  • Body Height:

    2.8 mm

  • Body Length or Diameter:

    7 mm

  • Housing:

    PLASTIC

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Bits:

    12

  • Operating Current-Max:

    10 mA

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -40 °C

  • Output Range:

    0.1-4.85V

  • Output Type:

    ANALOG VOLTAGE

  • Package Shape/Style:

    SQUARE

  • Port Type:

    HOLE

  • Pressure Range-Max:

    23.9 Psi

  • Pressure Range-Min:

    8.7 Psi

  • Pressure Sensing Mode:

    ABSOLUTE

  • Response Time:

    1000 µs

  • Sensors/Transducers Type:

    PRESSURE SENSOR,PIEZORESISTIVE

  • Supply Voltage-Max:

    5.5 V

  • Supply Voltage-Min:

    4.5 V

  • Surface Mount:

    YES

  • Termination Type:

    SOLDER
