KSJ0V43180SHLFTR - LITTELFUSE

KSJ0V43180SHLFTR Details

• Manufacturer Part Number:

  KSJ0V43180SHLFTR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Country Of Origin:

  France

• ECCN Code:

  EAR99

• HTS Code:

  8536.50.90.40

• Manufacturer:

  Littelfuse Inc

• YTEOL:

  0

• Body Breadth:

  7.7 mm

• Body Length or Diameter:

  8.77 mm

• Center Contact Material:

  GOLD

• Circuit Configuration:

  1X1

• Contact Bounce Time-Max:

  1 ms

• Contact Current(DC)-Max:

  0.01 A

• Contact (DC) Max Power Rating R Load:

  0.2VA@32VDC

• Contact (DC) Max Rating R Load:

  0.01A@32VDC

• Contact Resistance:

  0.1 mΩ

• Contact Voltage(DC)-Max:

  32 V

• Dielectric Withstand Volts:

  250VRMS V

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  GOLD

• Insulation Resistance:

  1000000000 Ω

• Mounting Feature:

  THROUGH HOLE-RIGHT ANGLE

• Number of Switches:

  1

• Operating Force-Max:

  3.3 N

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• PCB Hole Count:

  4

• Packing Method:

  BOX

• Sealing:

  IP60

• Solderability:

  WAVE

• Surface Mount:

  NO

• Switch Action:

  MOMENTARY

• Switch Function:

  SPST

• Switch Type:

  KEYPAD SWITCH

• Terminal Length:

  0.187 inch

• Termination Type:

  SOLDER
