KSWA-2-46+ - Mini-Circuits

KSWA-2-46+ Details

• Manufacturer Part Number:

  KSWA-2-46+

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• Manufacturer:

  Mini-Circuits

• YTEOL:

  0

• 1dB Compression Point:

  27 dBm

• Characteristic Impedance:

  50 Ω

• Construction:

  COMPONENT

• Input Power-Max (CW):

  26.99 dBm

• Insertion Loss-Max:

  2.6 dB

• Isolation-Min:

  25 dB

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Frequency-Max:

  4600 MHz

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.4

• Port Termination:

  ABSORPTIVE

• RF/Microwave Device Type:

  SPDT

• Surface Mount:

  YES

• Technology:

  GAAS

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier

• VSWR-Max:

  1.94
