KUEP-3D17-12 - TE Connectivity

KUEP-3D17-12 Details

• Manufacturer Part Number:

  KUEP-3D17-12

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• HTS Code:

  8536.49.00.50

• Manufacturer:

  TE Connectivity

• YTEOL:

  0

• Body Breadth:

  35.7 mm

• Body Height:

  48.4 mm

• Body Length or Diameter:

  38.9 mm

• Coil Current(DC)-Max:

  0.1 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  1200 mW

• Coil Resistance:

  120 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil Voltage-Nom:

  150 V

• Coil/Input Supply Type:

  DC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact (DC) Max Rating R Load:

  10A@150VDC

• Contact Voltage(DC)-Max:

  150 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  2200 Vrms

• Dielectric Strength Between Open Contacts:

  1200 Vrms

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER CADMIUM OXIDE

• Input Switching Control Type:

  Random

• Insulation Resistance:

  100000000 Ω

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  9

• Operate Time:

  15 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -45 °C

• Physical Dimension:

  38.9mm x 35.7mm x 48.4mm

• Reference Standard:

  CSA; UL

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM X

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  10 ms

• Sealing:

  DUST PROOF

• Surface Mount:

  NO

• Terminal Length:

  0.001000762001524003 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  85 g
