KWS5A-5 - TDK Lambda

KWS5A-5 Details

• Manufacturer Part Number:

  KWS5A-5

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Transferred

• Package Description:

  PACKAGE-4

• ECCN Code:

  EAR99

• Manufacturer:

  TDK-Lambda Corporation

• Additional Feature:

  ALSO OPERATES WITH 120 TO 370 VDC

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Input Voltage-Max:

  265 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-PDMA-P4

• Length:

  38.1 mm

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  55 °C

• Operating Temperature-Min:

  -10 °C

• Output Voltage-Max:

  5.25 V

• Output Voltage-Min:

  4.75 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  22 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  COMMERCIAL

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  5 W

• Trim/Adjustable Output:

  NO

• Width:

  25.4 mm
