L201316Q-251MHF - ITG Electronics

L201316Q-251MHF Details

• Manufacturer Part Number:

  L201316Q-251MHF

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  DIP

• ECCN Code:

  EAR99

• HTS Code:

  8504.50.80.00

• Manufacturer:

  ITG Electronics Inc

• Construction:

  DIP

• Core Material:

  METAL ALLOY POWDER

• DC Resistance:

  0.017 Ω

• Inductance-Nom (L):

  245 µH

• Inductor Application:

  HIGH CURRENT INDUCTOR

• Inductor Type:

  GENERAL PURPOSE INDUCTOR

• Number of Functions:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Height:

  31.6 mm

• Package Length:

  32 mm

• Package Style:

  DIP

• Package Width:

  32 mm

• Rated Current-Max:

  15.5 A

• Reference Standard:

  AEC-Q200

• Shape/Size Description:

  RECTANGULAR PACKAGE

• Shielded:

  NO

• Special Feature:

  DC RESISTANCE IS MEASURED AT 10%

• Surface Mount:

  NO

• Terminal Placement:

  RADIAL

• Terminal Shape:

  FLAT

• Test Frequency:

  0.01 MHz

• Tolerance:

  20%
