L4985ATR - STMicroelectronics

Description: CCM PFC controller with High Voltage start-up

Download L4985ATR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
L4985ATR - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
L4985ATR - STMicroelectronics PCB footprint - Small Outline Packages - Small Outline Packages - L5970D
click to zoom
3D Models
L4985ATR - STMicroelectronics - 3D model - Small Outline Packages - L5970D
click to zoom

L4985ATR Details

  • Manufacturer Part Number:

    L4985ATR

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    SOP-8

  • Country Of Origin:

    Mainland China

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Factory Lead Time:

    25 Weeks

  • Manufacturer:

    STMicroelectronics

  • YTEOL:

    7

  • Analog IC - Other Type:

    POWER FACTOR CONTROLLER

  • Control Mode:

    CURRENT-MODE

  • Control Technique:

    PULSE WIDTH MODULATION

  • Input Voltage-Max:

    24.5 V

  • Input Voltage-Min:

    10 V

  • Input Voltage-Nom:

    15 V

  • JESD-30 Code:

    R-PDSO-G8

  • Length:

    4.9 mm

  • Number of Functions:

    1

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    125 °C

  • Operating Temperature-Min:

    -25 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    SOP

  • Package Equivalence Code:

    SOP8,.25

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Seated Height-Max:

    1.75 mm

  • Supply Current-Max (Isup):

    4.7 mA

  • Surface Mount:

    YES

  • Switcher Configuration:

    BOOST

  • Switching Frequency-Max:

    71 kHz

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    1.27 mm

  • Terminal Position:

    DUAL

  • Width:

    3.9 mm

L4985ATR Frequently Asked Questions (FAQs)

  • The maximum input voltage that can be applied to the L4985ATR is 30V, but it's recommended to keep it below 28V for reliable operation.
  • To ensure stability, make sure to follow the recommended layout and component placement guidelines, use a sufficient output capacitor, and add a 10nF capacitor between the VREF and GND pins.
  • The minimum input voltage required for the L4985ATR to operate is 7V, but it's recommended to keep it above 8V for reliable startup and operation.
  • The L4985ATR is rated for operation up to 150°C, but it's recommended to derate the output current and voltage according to the temperature derating curve in the datasheet to ensure reliable operation.
  • The output voltage of the L4985ATR can be calculated using the formula: VOUT = VREF x (1 + R1/R2), where VREF is the internal reference voltage (2.5V), and R1 and R2 are the resistors connected to the VOUT pin.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

L4985ATR Overview

Use the download button to access the L4985ATR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like L4985, or try a keyword search, such as Switching Regulator or Controllers
