Technical Content
Part Image

L9907 - STMicroelectronics

Description: Motor / Motion / Ignition Controllers & Drivers Motor Bridge for Headlight Adjustment, PTS Smartpower

Download L9907 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
L9907 - STMicroelectronics - PCB symbol
click to zoom
PCB Footprints
L9907 - STMicroelectronics PCB footprint - Quad Flat Packages - Quad Flat Packages - TQFP64 (10x10x1 mm exp. pad down)
click to zoom
3D Models
L9907 - STMicroelectronics - 3D model - Quad Flat Packages - TQFP64 (10x10x1 mm exp. pad down)
click to zoom

L9907 Details

  • Manufacturer Part Number:

    L9907

  • Brand Name:

    STMicroelectronics

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Country Of Origin:

    Malaysia

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.60

  • Manufacturer:

    STMicroelectronics

  • Analog IC - Other Type:

    3-PHASE BRUSHLESS DC MOTOR CONTROLLER

  • JESD-30 Code:

    S-PQFP-G64

  • JESD-609 Code:

    e4

  • Length:

    10 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    64

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTFQFP

  • Package Equivalence Code:

    HQFP64,.40SQ,20

  • Package Shape:

    SQUARE

  • Package Style:

    FLATPACK, HEAT SINK/SLUG, THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Screening Level:

    AEC-Q100

  • Seated Height-Max:

    1.2 mm

  • Supply Current-Max (Isup):

    20 mA

  • Supply Voltage-Max (Vsup):

    5.25 V

  • Supply Voltage-Min (Vsup):

    3.2 V

  • Supply Voltage-Nom (Vsup):

    3.3 V

  • Surface Mount:

    YES

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    10 mm

L9907 Frequently Asked Questions (FAQs)

  • STMicroelectronics provides a recommended PCB layout in the application note AN4391, which includes guidelines for component placement, routing, and thermal management to ensure optimal performance and thermal dissipation.
  • The selection of the inductor depends on the specific application requirements, such as the input voltage, output voltage, and current rating. STMicroelectronics provides a list of recommended inductors in the datasheet, and also offers an inductor selection tool on their website to help with the selection process.
  • The maximum junction temperature of the L9907 is 150°C, as specified in the datasheet. However, it's recommended to keep the junction temperature below 125°C to ensure reliable operation and long-term reliability.
  • The L9907 is rated for operation up to 105°C ambient temperature, but it's not recommended to use it in high-temperature environments above 125°C without proper thermal management and derating. Consult the datasheet and application notes for more information on thermal management and derating.
  • STMicroelectronics provides a troubleshooting guide in the application note AN4391, which covers common issues and their solutions, such as output voltage regulation, current limiting, and thermal shutdown. Additionally, the datasheet provides a list of possible faults and their corresponding fault flags.

Trust Checks

This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

L9907 Overview

Use the download button to access the L9907 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search or try a keyword search, such as Motion Control Electronics
