Tamura recommends a 4-layer PCB with a solid ground plane and a separate layer for the output voltage. The input and output capacitors should be placed as close as possible to the IC, and the output inductor should be placed on the same layer as the output capacitor.
To ensure stable operation, it's essential to follow the recommended operating conditions, including input voltage, output voltage, and output current. Additionally, the device should be mounted on a heat sink to prevent overheating, and the PCB should be designed to minimize thermal resistance.
The maximum allowed input voltage ripple is 10% of the nominal input voltage. Exceeding this limit may affect the device's performance and reliability.
While it's possible to use a different inductor value or type, it's not recommended. The recommended inductor value and type are optimized for the device's performance and efficiency. Using a different inductor may affect the device's stability, efficiency, and output voltage regulation.
To troubleshoot issues, start by verifying the PCB layout and component values against the recommended design. Check for any signs of overheating, and ensure that the input and output capacitors are of sufficient value and quality. If the issue persists, consult the Tamura application note or contact their technical support team for further assistance.
