LC79401KNE - onsemi

LC79401KNE Details

• Manufacturer Part Number:

  LC79401KNE

• Part Life Cycle Code:

  Active

• Package Description:

  QIP-100

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  onsemi

• YTEOL:

  6.6

• Data Input Mode:

  PARALLEL

• Display Mode:

  DOT MATRIX; SEGMENT

• Input Characteristics:

  STANDARD

• Interface IC Type:

  LIQUID CRYSTAL DISPLAY DRIVER

• JESD-30 Code:

  R-PQFP-G100

• Length:

  20 mm

• Multiplexed Display Capability:

  NO

• Number of Functions:

  1

• Number of Segments:

  80

• Number of Terminals:

  100

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -20 °C

• Output Polarity:

  TRUE

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  QFP

• Package Equivalence Code:

  QFP100,.7X.9

• Package Shape:

  RECTANGULAR

• Package Style:

  FLATPACK

• Seated Height-Max:

  3 mm

• Supply Current-Max:

  4 mA

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  2.7 V

• Supply Voltage1-Max:

  32 V

• Supply Voltage1-Min:

  12 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  OTHER

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  QUAD

• Width:

  14 mm

• fmax-Min:

  6 MHz
