LCD12C - ProTek Devices

LCD12C Details

• Manufacturer Part Number:

  LCD12C

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  DO-201

• Package Description:

  PLASTIC, DIP-16

• Pin Count:

  16

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  ProTek Devices

• YTEOL:

  4

• Additional Feature:

  LOW CAPACITANCE

• Breakdown Voltage-Min:

  13.3 V

• Breakdown Voltage-Nom:

  13.3 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  23.5 V

• Configuration:

  8 BANKS, COMMON BIPOLAR TERMINAL, 2 ELEMENTS

• Diode Capacitance-Min:

  25 pF

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-201

• JESD-30 Code:

  R-PDIP-T16

• JESD-609 Code:

  e0

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  800 W

• Number of Elements:

  16

• Number of Terminals:

  16

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  245

• Polarity:

  BIDIRECTIONAL

• Power Dissipation-Max:

  5 W

• Qualification Status:

  Not Qualified

• Rep Pk Reverse Voltage-Max:

  12 V

• Reverse Current-Max:

  4 µA

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  THROUGH-HOLE

• Terminal Position:

  DUAL
